Table Top Diefold Wrapper Brochure

For small items and individual wrapping for candies and other small items, the TTDF-Mini offers a simple, easy to use, inexpensive wrapping process. The TTDF 1 and 2 offer opportunities to automate the wrapping of baked goods, candy bars and other products.

  • The sealing goes on the bottom. This makes it easy to accommodate products that do not have flat or rigid sides or are too short for side sealing.
  • Pretreated paper, paper-backed foil or clear oriented polypropylene can be used
  • Round or rectangular products can be wrapped on the TTDF.

ttdf img1 Table Top Diefold Wrapper Brochure

Performance and Ease of Use

The TTDF cycles up to 15+ strokes per minute. Throughput depends on operator. Easy operation by entry-level operators makes it possible to spend valuable time on higher level requirements.

VALUE WRAPPING

Low acquisition, operation & maintenance costs render the TTDF desirable to anyone interested in venturing into attractive wrapping without significant financial risk.

ttdf img2 Table Top Diefold Wrapper Brochure

PACKAGE SIZE RANGE

Model

Length

Width

Height

Max

Min

Max

Min

Max

Min

TTDF-mini

1.25”

.875”

1”

1.0”

1.0”

.5”

TTDF-1

6.50

2.75

3.0

1.0

1.5

.5

TTDF-2

8.0

3.5

4.0

1.875

3.0

.5

Machine Dimensions
Model

Length

Width

Height

TTDF-mini

24”

24”

18”

TTDF-1

30

30

24

TTDF-2

36

30

24

*All specifications subject to change. Maximum product throughput will vary depending on package dimensions and operator.
**Package Machinery Company Inc. reserves the right to modify any and all of the following listed features, specifications, and option packages.

ttdf img3 Table Top Diefold Wrapper BrochureMax Stroke Speed: up to15 strokes per minute
Standard Electrical:110V/1Ph/60Hz, 10 amp or optional 230/1/50
Air Requirements: Std. shop air or small air compressor
Weight: 60 pounds
Options: Rotary product twist wrap, Heat seal

Can be used with TTRB bander for chocolate bar wrapping
For further information, contact sales@packagemachinery.com
